دیتاشیت CS30-16IO1

CS30-16io1

مشخصات دیتاشیت

نام دیتاشیت CS30-16io1
حجم فایل 381.361 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت CS30-16io1

CS30-16io1 Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: One-way thyristor
  • Datasheet: Littelfuse/IXYS CS30-16IO1
  • Holding Current (Ih): 100mA
  • Operating Temperature: -40°C~+150°C
  • Gate Trigger Current(Igt): 55mA
  • Gate Trigger Voltage (Vgt): 1V
  • RMS On-State Current(It (rms)): 49A
  • Peak Forward On?State Voltage (Vtm): 1.63V
  • Peak Repetitive Off?State Voltage (Vdrm): 1.6kV
  • Package: TO-247-3
  • Manufacturer: IXYS
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Voltage - Off State: 1.6kV
  • Voltage - Gate Trigger (Vgt) (Max): 1V
  • Current - Gate Trigger (Igt) (Max): 55mA
  • Voltage - On State (Vtm) (Max): 1.63V
  • Current - On State (It (AV)) (Max): 30A
  • Current - On State (It (RMS)) (Max): 49A
  • Current - Hold (Ih) (Max): 100mA
  • Current - Off State (Max): 50µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 400A, 430A
  • Mounting Type: Through Hole
  • Package / Case: TO-3P-3 Full Pack
  • Supplier Device Package: TO-247AD
  • detail: SCR 1.6kV 49A Standard Recovery Through Hole TO-247AD
