دیتاشیت IXGR48N60C3D1
مشخصات دیتاشیت
| نام دیتاشیت |
IXGR48N60C3D1
|
| حجم فایل |
213.661
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
GenX3™
-
Packaging:
Tube
-
Part Status:
Active
-
IGBT Type:
PT
-
Voltage - Collector Emitter Breakdown (Max):
600V
-
Current - Collector (Ic) (Max):
56A
-
Current - Collector Pulsed (Icm):
230A
-
Vce(on) (Max) @ Vge, Ic:
2.7V @ 15V, 30A
-
Power - Max:
125W
-
Switching Energy:
410µJ (on), 230µJ (off)
-
Input Type:
Standard
-
Gate Charge:
77nC
-
Td (on/off) @ 25°C:
19ns/60ns
-
Test Condition:
400V, 30A, 3Ohm, 15V
-
Reverse Recovery Time (trr):
25ns
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
ISOPLUS247™
-
Supplier Device Package:
ISOPLUS247™
-
Base Part Number:
IXG*48N60
