دیتاشیت DSI45-16A

DSI45-16A

مشخصات دیتاشیت

نام دیتاشیت DSI45-16A
حجم فایل 338.463 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت DSI45-16A

DSI45-16A Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: Littelfuse/IXYS DSI45-16A
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 1.6kV
  • Operating Temperature: -40°C~+175°C@(Tvj)
  • Forward Voltage (Vf@If): 1.26V@45A
  • Reverse Leakage Current: 40uA@1.6kV
  • Reverse Recovery Time (trr): -
  • Average Rectified Current (Io): 45A
  • Package: TO-247
  • Manufacturer: IXYS
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 1600V
  • Current - Average Rectified (Io): 45A
  • Voltage - Forward (Vf) (Max) @ If: 1.28V @ 45A
  • Speed: Standard Recovery >500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 20µA @ 1600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-247-2
  • Supplier Device Package: TO-247AD
  • Operating Temperature - Junction: -40°C ~ 175°C
  • detail: Diode Standard 1600V 45A Through Hole TO-247AD
