دیتاشیت IXFN27N80Q
مشخصات دیتاشیت
| نام دیتاشیت | IXFK(27,25)N80, IXFN(27,25)N80 |
|---|---|
| حجم فایل | 220.952 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت IXFK(27,25)N80, IXFN(27,25)N80 |
IXFK(27,25)N80, IXFN(27,25)N80 Datasheet |
|---|
مشخصات
- Manufacturer: IXYS
- Series: HiPerFET™
- Packaging: Tube
- Part Status: Not For New Designs
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 800V
- Current - Continuous Drain (Id) @ 25°C: 27A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V, 15V
- Rds On (Max) @ Id, Vgs: 300mOhm @ 13.5A, 10V
- Vgs(th) (Max) @ Id: 4.5V @ 8mA
- Gate Charge (Qg) (Max) @ Vgs: 400nC @ 10V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 9740pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 520W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Chassis Mount
- Supplier Device Package: SOT-227B
- Package / Case: SOT-227-4, miniBLOC
- detail: N-Channel 800V 27A (Tc) 520W (Tc) Chassis Mount SOT-227B
