دیتاشیت NRF8001-R2Q32-T
مشخصات دیتاشیت
| نام دیتاشیت | NRF8001 Specification |
|---|---|
| حجم فایل | 1756.446 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 161 |
دانلود دیتاشیت NRF8001 Specification |
NRF8001 Specification Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 1Mbps
- Datasheet: Nordic Semicon NRF8001-R2Q32-T
- Interface: I2C,SPI,UART
- Applications: Bluetooth
- Frequency Range: 2.4GHz
- Receive Current: 11.1mA
- Operating Voltage: 1.9V~3.6V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 6.6mA
- Package: QFN-32-EP(5x5)
- Manufacturer: Nordic Semicon
- Series: -
- Packaging: Tray
- Part Status: Active
- Type: TxRx Only
- RF Family/Standard: Bluetooth
- Protocol: Bluetooth v4.0
- Modulation: GFSK
- Frequency: 2.4GHz
- Data Rate (Max): 1Mbps
- Power - Output: 0dBm
- Sensitivity: -87dBm
- Memory Size: -
- Serial Interfaces: I²C, SPI, UART
- Voltage - Supply: 1.9V ~ 3.6V
- Current - Receiving: 11.1mA ~ 14.6mA
- Current - Transmitting: 6.6mA ~ 12.7mA
- Mounting Type: Surface Mount
- Package / Case: 32-VFQFN Exposed Pad
- Supplier Device Package: 32-QFN (5x5)
- detail: IC RF TxRx Only Bluetooth Bluetooth v4.0 2.4GHz 32-VFQFN Exposed Pad
