دیتاشیت LP2985A-50DBVR
مشخصات دیتاشیت
| نام دیتاشیت |
LP2985
|
| حجم فایل |
1425.258
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
28
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments LP2985A-50DBVR
-
Output Type:
Fixed
-
Output Current:
150mA
-
Output Voltage:
5V
-
Dropout Voltage:
580mV@(150mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
16V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
95uA
-
Power Supply Rejection Ratio (PSRR):
45dB@(1kHz)
-
Package:
SOT-23-5
-
Manufacturer:
Texas Instruments
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Package / Case:
SC-74A, SOT-753
-
Control Features:
Enable
-
Series:
-
-
Voltage Dropout (Max):
0.58V @ 150mA
-
Current - Quiescent (Iq):
95µA
-
Number of Regulators:
1
-
Supplier Device Package:
SOT-23-5
-
Protection Features:
Over Current, Over Temperature, Short Circuit
-
Output Configuration:
Positive
-
PSRR:
45dB (1kHz)
-
Packaging:
Cut Tape (CT)
-
Base Part Number:
LP298
-
Part Status:
Active
-
Current - Output:
150mA
-
Mounting Type:
Surface Mount
-
Current - Supply (Max):
2.5mA
-
Voltage - Input (Max):
16V
-
detail:
Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
