SN74LVC3G17DCTR Datasheet
Datasheet specifications
| Datasheet's name | SN74LVC3G17DCTR |
|---|---|
| File size | 101.518 KB |
| File type | |
| Number of pages | 17 |
Download Datasheet SN74LVC3G17DCTR |
Download Datasheet |
|---|
Other documentations
Logic Guide 20 pages
Signal Switch Data Book 1267 pages
SN74LVC3G17 Datasheet 25 pages
Digital Logic Data Book 794 pages
Technical specifications
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74LVC3G17DCTR
- Input type: Schmitt Trigger
- output type: Push Pull
- Sink Current: 32mA
- Source Current: 32mA
- Supply Voltage: 1.65V~5.5V
- Operating Temperature: -40°C~+125°C
- Package: MSOP-8
- Manufacturer: Texas Instruments
- Number of Elements: 3
- Packaging: Cut Tape (CT)
- Base Part Number: SN74LVC3G
- Package / Case: 8-LSSOP, 8-MSOP (0.110", 2.80mm Width)
- Number of Bits per Element: 1
- Voltage - Supply: 1.65V ~ 5.5V
- Mounting Type: Surface Mount
- Series: 74LVC
- Supplier Device Package: SM8 (SSOP)
- Logic Type: Buffer, Non-Inverting
- Current - Output High, Low: 32mA, 32mA
- Part Status: Active
- detail: Buffer, Non-Inverting 3 Element 1 Bit per Element Push-Pull Output SM8 (SSOP)
