TPS79901DDCR دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TPS79901DDCR	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS79901DDCR
Output Type: Adjustable
Output Current: 200mA
Output Voltage: 1.2V~6.5V
Dropout Voltage: 175mV@(200mA)
Output Polarity: Positive
Number of Outputs: 1
Maximum Input Voltage: 6.5V
Operating Temperature: -40°C~+125°C
Quiescent Current (Ground Current): 60uA
Power Supply Rejection Ratio (PSRR): 70dB@(100Hz),38dB@(100kHz)
Package: SOT-23-5
Manufacturer: Texas Instruments
Number of Regulators: 1
Current - Quiescent (Iq): 60µA
Base Part Number: TPS799
Voltage - Input (Max): 6.5V
Supplier Device Package: SOT-23-5
Voltage - Output (Max): 6.5V
Packaging: Cut Tape (CT)
Mounting Type: Surface Mount
Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Control Features: Enable
Voltage - Output (Min/Fixed): 1.2V
Voltage Dropout (Max): 0.18V @ 200mA
Part Status: Active
Series: -
Current - Output: 200mA
PSRR: 70dB ~ 38dB (100Hz ~ 100kHz)
Output Configuration: Positive
Package / Case: SOT-23-5 Thin, TSOT-23-5
detail: Linear Voltage Regulator IC 1 Output 200mA SOT-23-5
