دیتاشیت TPS70933DBVR

مشخصات دیتاشیت

دانلود دیتاشیت TPS709 Datasheet	TPS709 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS70933DBVR
Output Type: Fixed
Output Current: 150mA
Output Voltage: 3.3V
Dropout Voltage: 1.4V@(150mA)
Output Polarity: Positive
Number of Outputs: 1
Maximum Input Voltage: 30V
Operating Temperature: -40°C~+125°C
Quiescent Current (Ground Current): 2.05uA
Power Supply Rejection Ratio (PSRR): 80dB@(10Hz),52dB@(1kHz)
Package: SOT-23-5
Manufacturer: Texas Instruments
Series: -
Control Features: Enable
Voltage - Output (Max): -
Current - Quiescent (Iq): 2.05µA
Supplier Device Package: SOT-23-5
Voltage Dropout (Max): 1.4V @ 150mA
Number of Regulators: 1
PSRR: 80dB ~ 52dB (10Hz ~ 1kHz)
Mounting Type: Surface Mount
Voltage - Output (Min/Fixed): 3.3V
Current - Output: 150mA
Voltage - Input (Max): 30V
Current - Supply (Max): 350µA
Protection Features: Over Current, Over Temperature, Reverse Current, Under Voltage Lockout (UVLO)
Packaging: Cut Tape (CT)
Base Part Number: TPS709
Package / Case: SC-74A, SOT-753
Part Status: Active
Output Configuration: Positive
detail: Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
