دیتاشیت TL074CDT

TL074

مشخصات دیتاشیت

نام دیتاشیت TL074
حجم فایل 1334.35 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت TL074

TL074 Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/FET InputAmplifiers
  • Datasheet: STMicroelectronics TL074CDT
  • Number of Circuits: 4
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 30pA
  • Supply Current Per Channel: 1.4mA
  • Gain Bandwidth Product(GBP): 3MHz
  • Voltage - Input Offset(Vos): 3mV
  • Package: SOP-14
  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Amplifier Type: J-FET
  • Output Type: -
  • Slew Rate: 13V/µs
  • Gain Bandwidth Product: 3MHz
  • Current - Input Bias: 20pA
  • Voltage - Input Offset: 3mV
  • Current - Supply: 1.4mA
  • Current - Output / Channel: 40mA
  • Voltage - Supply, Single/Dual (±): 6V ~ 36V, ±3V ~ 18V
  • Mounting Type: Surface Mount
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 14-SO
  • Base Part Number: TL074
  • detail: J-FET Amplifier 4 Circuit 14-SO
