دیتاشیت LD1085D2T-R

LD1085xx

مشخصات دیتاشیت

نام دیتاشیت LD1085xx
حجم فایل 1200.736 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

دانلود دیتاشیت LD1085xx

LD1085xx Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 30V
  • Voltage - Output (Min/Fixed): 1.25V
  • Voltage - Output (Max): 28.5V
  • Voltage Dropout (Max): 1.5V @ 3A
  • Current - Output: 3A
  • Current - Quiescent (Iq): 10mA
  • PSRR: 72dB (120Hz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Supplier Device Package: D2PAK
  • Base Part Number: LD1085
  • detail: Linear Voltage Regulator IC 1 Output 3A D2PAK
