دیتاشیت VIPER06HS

VIPER06

مشخصات دیتاشیت

نام دیتاشیت VIPER06
حجم فایل 1787.117 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت VIPER06

VIPER06 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: VIPer™ plus
  • Packaging: Tube
  • Part Status: Active
  • Output Isolation: Either
  • Internal Switch(s): Yes
  • Voltage - Breakdown: 800V
  • Topology: Buck, Flyback
  • Voltage - Start Up: 13V
  • Voltage - Supply (Vcc/Vdd): 11.5V ~ 23.5V
  • Duty Cycle: 70%
  • Frequency - Switching: 115kHz
  • Power (Watts): 8W
  • Fault Protection: Current Limiting, Open Loop, Over Temperature
  • Control Features: -
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Package / Case: 10-SOP (0.154", 3.90mm Width)
  • Supplier Device Package: 10-SSO
  • Mounting Type: Surface Mount
  • Base Part Number: VIPER06
  • detail: Converter Offline Buck, Flyback Topology 115kHz 10-SSO
