دیتاشیت INA117P

INA117

مشخصات دیتاشیت

نام دیتاشیت INA117
حجم فایل 907.687 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت INA117

INA117 Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Differential OpAmps
  • Datasheet: Texas Instruments INA117P
  • -3db Bandwidth: 200kHz
  • Number of Circuits: 1
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): -
  • Gain Bandwidth Product(GBP): -
  • Voltage - Input Offset(Vos): 120uV
  • Package: PDIP-8
  • Manufacturer: Texas Instruments
  • Voltage - Input Offset: 120µV
  • Current - Supply: 1.5mA
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Amplifier Type: Differential
  • Series: -
  • Part Status: Active
  • Base Part Number: INA117
  • Voltage - Supply, Single/Dual (±): ±5V ~ 18V
  • Packaging: Tube
  • Output Type: -
  • Supplier Device Package: 8-PDIP
  • Slew Rate: 2.6V/µs
  • Current - Output / Channel: 20mA
  • detail: Differential Amplifier 1 Circuit 8-PDIP
