دیتاشیت BTW68-800RG

BTW68

مشخصات دیتاشیت

نام دیتاشیت BTW68
حجم فایل 70.164 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت BTW68

BTW68 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Voltage - Off State: 800V
  • Voltage - Gate Trigger (Vgt) (Max): 1.5V
  • Current - Gate Trigger (Igt) (Max): 50mA
  • Voltage - On State (Vtm) (Max): 2.1V
  • Current - On State (It (AV)) (Max): 19A
  • Current - On State (It (RMS)) (Max): 30A
  • Current - Hold (Ih) (Max): 75mA
  • Current - Off State (Max): 20µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 400A, 420A
  • SCR Type: Standard Recovery
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Through Hole
  • Package / Case: TOP-3
  • Supplier Device Package: TOP3
  • Base Part Number: BTW68
  • detail: SCR 800V 30A Standard Recovery Through Hole TOP3
