دیتاشیت L296P

مشخصات دیتاشیت

دانلود دیتاشیت L296(P) Datasheet	L296(P) Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: STMicroelectronics L296P
Output Type: Adjustable
Input Voltage: 9V~46V
Output Voltage: 5.1V~40V
Number of Outputs: 1
Switching Frequency: 100kHz
Output Current (Max): 4A
Operating Temperature: -40°C~+150°C@(TJ)
Synchronous Rectification: NO
Package: Multiwatt-15
Manufacturer: STMicroelectronics
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 9V
Voltage - Input (Max): 46V
Voltage - Output (Min/Fixed): 5.1V
Voltage - Output (Max): 40V
Current - Output: 4A
Frequency - Switching: 100kHz
Synchronous Rectifier: No
Mounting Type: Through Hole
Package / Case: Multiwatt-15 (Vertical, Bent and Staggered Leads)
Supplier Device Package: 15-Multiwatt
Base Part Number: L296
detail: Buck Switching Regulator IC Positive Adjustable 5.1V 1 Output 4A Multiwatt-15 (Vertical, Bent and Staggered Leads)
