دیتاشیت DAC7731E

DAC7731

مشخصات دیتاشیت

نام دیتاشیت DAC7731
حجم فایل 762.618 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت DAC7731

DAC7731 Datasheet

مشخصات

  • Part Status: Active
  • Voltage - Supply, Digital: 5V
  • Mounting Type: Surface Mount
  • Package / Case: 24-SSOP (0.209", 5.30mm Width)
  • Settling Time: 5µs
  • Series: -
  • INL/DNL (LSB): ±6 (Max), ±4 (Max)
  • Differential Output: No
  • Operating Temperature: -40°C ~ 85°C
  • Voltage - Supply, Analog: ±11.4V ~ 15.75V, -4.75V ~ -15.75V
  • Reference Type: External, Internal
  • Data Interface: SPI
  • Base Part Number: DAC7731
  • Number of Bits: 16
  • Packaging: Tube
  • Manufacturer: Texas Instruments
  • Output Type: Voltage - Buffered
  • Number of D/A Converters: 1
  • Supplier Device Package: 24-SSOP
  • Architecture: R-2R
  • detail: 16 Bit Digital to Analog Converter 1 24-SSOP
