دیتاشیت ISO7221CHD
مشخصات دیتاشیت
| نام دیتاشیت |
ISO7221C-HT
|
| حجم فایل |
598.906
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
18
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Digital Isolators
-
Data Rate:
25Mbps
-
Datasheet:
Texas Instruments ISO7221CHD
-
Applications:
General-purpose
-
Supply Voltage:
3V~5.5V
-
Forward Channel:
1
-
Reverse channel:
1
-
Number of Channels:
2
-
Isolation Technology:
电容隔离
-
Operating Temperature:
-55°C~+175°C
-
Voltage Isolation or Not:
Without voltage isolation
-
Package:
SOP-8
-
Manufacturer:
Texas Instruments
-
Type:
General Purpose
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Mounting Type:
Surface Mount
-
Isolated Power:
No
-
Voltage - Supply:
3V ~ 5.5V
-
Supplier Device Package:
8-SOIC
-
Part Status:
Active
-
Base Part Number:
ISO7221
-
Pulse Width Distortion (Max):
2ns
-
Technology:
Capacitive Coupling
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Channel Type:
Unidirectional
-
Inputs - Side 1/Side 2:
1/1
-
Rise / Fall Time (Typ):
1ns, 1ns
-
Series:
-
-
Packaging:
Bulk
-
Propagation Delay tpLH / tpHL (Max):
43ns, 43ns
-
Voltage - Isolation:
4000Vpk
-
detail:
General Purpose Digital Isolator 4000Vpk 2 Channel 25Mbps 25kV/µs CMTI 8-SOIC (0.154", 3.90mm Width)
