دیتاشیت CD74HC74M96
مشخصات دیتاشیت
| نام دیتاشیت |
CD54,74HC(T)74
|
| حجم فایل |
999.428
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
19
|
مشخصات
-
RoHS:
true
-
Type:
D-Type
-
Series:
74HC
-
Category:
Logic ICs/Flip Flops
-
Function:
置位和复位
-
Datasheet:
Texas Instruments CD74HC74M96
-
Output Type:
互补型
-
Sink Current:
5.2mA
-
Trigger Type:
上升沿
-
Source Current:
5.2mA
-
Supply Voltage:
2V~6V
-
Clock Frequency:
50MHz
-
Input Capacitance:
10pF
-
Number of Elements:
2
-
Operating Temperature:
-55°C~+125°C
-
Quiescent Current (Iq):
4uA
-
Maximum Propagation Delay:
30ns@6V,50pF
-
Number of Bits per Element:
1
-
Package:
SOP-14
-
Manufacturer:
Texas Instruments
-
Voltage - Supply:
2V ~ 6V
-
Part Status:
Active
-
Base Part Number:
74HC74
-
Current - Quiescent (Iq):
4µA
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Max Propagation Delay @ V, Max CL:
30ns @ 6V, 50pF
-
Mounting Type:
Surface Mount
-
Current - Output High, Low:
5.2mA, 5.2mA
-
Packaging:
Cut Tape (CT)
-
Supplier Device Package:
14-SOIC
-
detail:
Flip Flop 2 Element D-Type 1 Bit Positive Edge 14-SOIC (0.154", 3.90mm Width)
