دیتاشیت DRV10866DSCR

DRV10866

مشخصات دیتاشیت

نام دیتاشیت DRV10866
حجم فایل 2793.573 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت DRV10866

DRV10866 Datasheet

مشخصات

  • RoHS: true
  • Type: 无刷直流BLDC
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: Texas Instruments DRV10866DSCR
  • Interface: PWM
  • Output Current: 800mA
  • Supply Voltage: 1.65V~5.5V
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Package: DFN-10-EP(3x3)
  • Manufacturer: Texas Instruments
  • Applications: Fan Motor Driver
  • Motor Type - AC, DC: Brushless DC (BLDC)
  • Motor Type - Stepper: -
  • Technology: Power MOSFET
  • Series: -
  • Voltage - Supply: 1.65V ~ 5.5V
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Packaging: Cut Tape (CT)
  • Package / Case: 10-WFDFN Exposed Pad
  • Step Resolution: -
  • Voltage - Load: 1.65V ~ 5.5V
  • Part Status: Active
  • Output Configuration: Half Bridge (3)
  • Base Part Number: DRV10866
  • Supplier Device Package: 10-WSON (3x3)
  • Mounting Type: Surface Mount
  • Current - Output: 800mA
  • detail: Motor Driver Power MOSFET PWM 10-WSON (3x3)
