دیتاشیت SN74HCT240N
مشخصات دیتاشیت
| نام دیتاشیت | SN54HCT240, SN74HCT240 |
|---|---|
| حجم فایل | 1373.807 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت SN54HCT240, SN74HCT240 |
SN54HCT240, SN74HCT240 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74HCT240N
- output type: Tri-State
- Logic Family: 74HCT
- Sink Current: 6mA
- Source Current: 6mA
- Supply Voltage: 4.5V~5.5V
- Number of Elements: 2
- Operating Temperature: -40°C~+85°C
- Number of Bits per Element: 4
- Package: PDIP-20
- Manufacturer: Texas Instruments
- Voltage - Supply: 4.5V ~ 5.5V
- Input Type: -
- Mounting Type: Through Hole
- Packaging: Tube
- Package / Case: 20-DIP (0.300", 7.62mm)
- Part Status: Active
- Current - Output High, Low: 6mA, 6mA
- Series: 74HCT
- Supplier Device Package: 20-PDIP
- Logic Type: Buffer, Inverting
- Base Part Number: SN74HCT
- detail: Buffer, Inverting 2 Element 4 Bit per Element 3-State Output 20-PDIP
