دیتاشیت SN74HCT373N

SN54HCT373, SN74HCT373

مشخصات دیتاشیت

نام دیتاشیت SN54HCT373, SN74HCT373
حجم فایل 1403.314 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت SN54HCT373, SN74HCT373

SN54HCT373, SN74HCT373 Datasheet

مشخصات

  • RoHS: true
  • Series: 74HCT
  • Category: Logic ICs/Latches
  • Datasheet: Texas Instruments SN74HCT373N
  • Logic Type: D-Typelocking Latch
  • Output Type: Tri-State
  • Sink Current: 6mA
  • Source Current: 6mA
  • Supply Voltage: 4.5V~5.5V
  • Propagation Delay: 25ns
  • OperatingTemperature: -40°C~+85°C
  • Package: DIP-20
  • Manufacturer: Texas Instruments
  • Independent Circuits: 1
  • Voltage - Supply: 4.5V ~ 5.5V
  • Circuit: 8:8
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Through Hole
  • Packaging: Tube
  • Package / Case: 20-DIP (0.300", 7.62mm)
  • Delay Time - Propagation: 25ns
  • Part Status: Active
  • Current - Output High, Low: 6mA, 6mA
  • Supplier Device Package: 20-PDIP
  • Base Part Number: SN74HCT
  • detail: D-Type Transparent Latch 1 Channel 8:8 IC Tri-State 20-PDIP
