دیتاشیت SN74LS164N
مشخصات دیتاشیت
| نام دیتاشیت | SN54164, SN54LS164, SN74164, SN74LS164 |
|---|---|
| حجم فایل | 1099.283 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت SN54164, SN54LS164, SN74164, SN74LS164 |
SN54164, SN54LS164, SN74164, SN74LS164 Datasheet |
|---|
مشخصات
- RoHS: true
- Series: 74LS
- Category: Logic ICs/Shifting Register
- Function: Serialtoparallel
- Datasheet: Texas Instruments SN74LS164N
- Output Type: Push-pull
- Supply Voltage: 4.75V~5.25V
- Number of Elements: 1
- Operating Temperature: 0°C~+70°C
- Number of Bits per Element: 8
- Package: DIP-14
- Manufacturer: Texas Instruments
- Voltage - Supply: 4.75V ~ 5.25V
- Part Status: Active
- Packaging: Tube
- Package / Case: 14-DIP (0.300", 7.62mm)
- Supplier Device Package: 14-PDIP
- Mounting Type: Through Hole
- Logic Type: Shift Register
- Base Part Number: SN74LS16
- detail: Shift Shift Register 1 Element 8 Bit 14-PDIP
