SM30T26CAY دیتاشیت

SM30T26CAY

مشخصات دیتاشیت

نام دیتاشیت SM30T26CAY
حجم فایل 58.668 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت SM30T26CAY

دانلود دیتاشیت

سایر مستندات

SM30TY Series 16 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: STMicroelectronics SM30T26CAY
  • Breakdown Voltage: 24.4V
  • Bidirectional Channels: 1
  • Maximum Clamping Voltage: 35.5V
  • Reverse Leakage Current (Ir): 0.2uA
  • Reverse Stand-Off Voltage (Vrwm): 22V
  • Peak Pulse Current (Ipp)@10/1000us: 84.5A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 3kW
  • Package: SMC(DO-214AB)
  • Manufacturer: STMicroelectronics
  • Series: Automotive, AEC-Q101, SM30TY, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 22V
  • Voltage - Breakdown (Min): 24.4V
  • Voltage - Clamping (Max) @ Ipp: 35.5V
  • Current - Peak Pulse (10/1000µs): 84.5A
  • Power - Peak Pulse: 3000W (3kW)
  • Power Line Protection: No
  • Applications: Automotive
  • Capacitance @ Frequency: -
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: DO-214AB, SMC
  • Supplier Device Package: SMC (DO-214AB)
  • Base Part Number: SM30T
  • detail: 35.5V Clamp 84.5A Ipp Tvs Diode Surface Mount SMC (DO-214AB)
