دیتاشیت L3GD20HTR
مشخصات دیتاشیت
| نام دیتاشیت |
L3GD20H
|
| حجم فایل |
2537.114
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
52
|
مشخصات
-
RoHS:
true
-
Category:
Sensors/Attitude Sensor/Gyroscope
-
Datasheet:
STMicroelectronics L3GD20HTR
-
Supply Voltage:
2.2V~3.6V
-
Axial Direction:
X,Y(Roll),Z(Yaw)
-
Operating Temperature:
-40°C~+85°C
-
Package:
LGA-16
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Digital
-
Axis:
X (Pitch), Y (Roll), Z (Yaw)
-
Range °/s:
±245, 500, 2000
-
Sensitivity (LSB/(°/s)):
8.75 ~ 70
-
Sensitivity (mV/°/s):
-
-
Bandwidth:
6.25Hz ~ 400Hz
-
Output Type:
I²C, SPI
-
Voltage - Supply:
2.2V ~ 3.6V
-
Current - Supply:
5mA
-
Features:
Adjustable Bandwidth, Selectable Scale, Sleep Mode, Temperature Sensor
-
Package / Case:
16-LGA
-
Base Part Number:
L3GD20
-
detail:
Gyroscope X (Pitch), Y (Roll), Z (Yaw) ±245, 500, 2000 6.25Hz ~ 400Hz I²C, SPI 16-LGA (3x3)
