دیتاشیت BLUENRG-132

مشخصات دیتاشیت

دانلود دیتاشیت BlueNRG-1 Datasheet	BlueNRG-1 Datasheet Datasheet

RoHS: true
Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
Data Rate: 1Mbps
Datasheet: STMicroelectronics BLUENRG-132
Interface: ADC,GPIO,I2C,SPI,UART
Applications: Bluetooth
Frequency Range: 2.4GHz
Receive Current: 7.7mA
Operating Voltage: 1.7V~3.6V
Operating Temperature: -40°C~+105°C
Current Of Transmitting: 15.1mA
Package: QFN-32-EP(5x5)
Manufacturer: STMicroelectronics
Series: BlueNRG
Packaging: Cut Tape (CT)
Part Status: Active
Type: TxRx + MCU
RF Family/Standard: Bluetooth
Protocol: Bluetooth v4.2
Modulation: -
Frequency: 2.4GHz
Data Rate (Max): 1Mbps
Power - Output: 8dBm
Sensitivity: -88dBm
Memory Size: 160kB Flash, 24kB RAM
Serial Interfaces: I²C, SPI, UART
GPIO: 15
Voltage - Supply: 1.7V ~ 3.6V
Current - Receiving: 7.7mA
Current - Transmitting: 15.1mA
Package / Case: 32-VFQFN Exposed Pad
detail: IC RF TxRx + MCU Bluetooth Bluetooth v4.2 2.4GHz 32-VFQFN Exposed Pad
