دیتاشیت LT1054IP
مشخصات دیتاشیت
| نام دیتاشیت |
LT1054IP
|
| حجم فایل |
87.96
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
36
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Datasheet:
Texas Instruments LT1054IP
-
Input Voltage:
3.5V~15V
-
Output Voltage:
3.5V~26.4V
-
Number of Outputs:
1
-
Switching Frequency:
25kHz
-
Output Current (Max):
100mA
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
PDIP-8
-
Manufacturer:
Texas Instruments
-
Current - Output:
100mA
-
Voltage - Input (Max):
15V
-
Frequency - Switching:
25kHz
-
Part Status:
Active
-
Base Part Number:
LT1054
-
Voltage - Output (Min/Fixed):
3.5V (-Vin, 2Vin)
-
Package / Case:
8-DIP (0.300", 7.62mm)
-
Series:
-
-
Packaging:
Tube
-
Synchronous Rectifier:
No
-
Topology:
Charge Pump
-
Output Configuration:
Positive or Negative
-
Output Type:
Adjustable (Fixed)
-
Voltage - Output (Max):
26.4V
-
Mounting Type:
Through Hole
-
Supplier Device Package:
8-PDIP
-
Voltage - Input (Min):
3.5V
-
detail:
Charge Pump Switching Regulator IC Positive or Negative Adjustable (Fixed) 3.5V (-Vin, 2Vin) 1 Output 100mA 8-DIP (0.300", 7.62mm)
