UCC3801N دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت UCC180x, 280x, 380x Datasheet-Isee	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Part Status: Active
Package / Case: 8-DIP (0.300", 7.62mm)
Packaging: Tube
Topology: Buck, Boost, Flyback, Forward Converter
Frequency - Switching: 46kHz
Supplier Device Package: 8-PDIP
Number of Outputs: 1
Serial Interfaces: -
Manufacturer: Texas Instruments
Synchronous Rectifier: No
Function: Step-Up, Step-Down, Step-Up/Step-Down
Clock Sync: No
Operating Temperature: 0°C ~ 70°C (TA)
Mounting Type: Through Hole
Output Configuration: Positive
Base Part Number: UCC380
Series: -
Output Type: Transistor Driver
Control Features: Frequency Control
Output Phases: 1
Duty Cycle (Max): 49%
Voltage - Supply (Vcc/Vdd): 7.4V ~ 12V
detail: Buck, Boost, Flyback, Forward Converter Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 8-PDIP
