دیتاشیت REF5020AID

REF5020AID

مشخصات دیتاشیت

نام دیتاشیت REF5020AID
حجم فایل 69.325 کیلوبایت
نوع فایل pdf
تعداد صفحات 39

REF5020AID

دانلود دیتاشیت

سایر مستندات

Analog Signal Chain Guide 11 pages

REF5020,25,30,40,45,50 Datasheet 40 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: Texas Instruments REF5020AID
  • Tolerance: ±0.1%
  • Output Type: Fixed
  • Input Voltage: 2.7V~18V
  • Output Current: 10mA
  • Output Voltage: 2.048V
  • Reference Type: series connection
  • Supply Current: 1.2mA
  • Noise - 10Hz to 10kHz: -
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Noise - 1/10Hz to 10Hz: 3uVp-p
  • Temperature Coefficient: 8ppm/°C
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Base Part Number: REF502
  • Voltage - Output (Min/Fixed): 2.048V
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Current - Output: 10mA
  • Packaging: Tube
  • Supplier Device Package: 8-SOIC
  • Series: -
  • Current - Supply: 1.2mA
  • Noise - 0.1Hz to 10Hz: 3µVp-p
  • Voltage - Input: 2.7V ~ 18V
