STPSC406D دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STPSC406D
|
|
حجم فایل
|
47.25
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
STMicroelectronics STPSC406D
-
Reverse Voltage (Vr):
600V
-
Forward Voltage (Vf@If):
1.9V@4A
-
Reverse Leakage Current (Ir):
50uA@600V
-
Average Rectified Current (Io):
4A
-
Package:
TO-220-2
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Silicon Carbide Schottky
-
Voltage - DC Reverse (Vr) (Max):
600V
-
Current - Average Rectified (Io):
4A
-
Voltage - Forward (Vf) (Max) @ If:
1.9V @ 4A
-
Speed:
No Recovery Time > 500mA (Io)
-
Reverse Recovery Time (trr):
0ns
-
Current - Reverse Leakage @ Vr:
50µA @ 600V
-
Capacitance @ Vr, F:
200pF @ 0V, 1MHz
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-2
-
Supplier Device Package:
TO-220AC
-
Operating Temperature - Junction:
-40°C ~ 175°C
-
Base Part Number:
STPSC406
-
detail:
Diode Silicon Carbide Schottky 600V 4A Through Hole TO-220AC
