دیتاشیت LM324AD

LM124, 224x, 324x

مشخصات دیتاشیت

نام دیتاشیت LM124, 224x, 324x
حجم فایل 1101.499 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت LM124, 224x, 324x

LM124, 224x, 324x Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LM324AD
  • -3db Bandwidth: -
  • Output Current: 30mA
  • Number of Circuits: 4
  • Operating Temperature: 0°C~+70°C
  • Current - Input Bias(Ib): 15nA
  • Gain Bandwidth Product(GBP): 1.3MHz
  • Package: SOP-14
  • Manufacturer: Texas Instruments
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Amplifier Type: General Purpose
  • Output Type: -
  • Slew Rate: 0.4V/µs
  • Gain Bandwidth Product: 1.3MHz
  • Current - Input Bias: 20nA
  • Voltage - Input Offset: 2mV
  • Current - Supply: 1.5mA
  • Current - Output / Channel: 70mA
  • Voltage - Supply, Single/Dual (±): 3V ~ 30V, ±1.5V ~ 15V
  • Mounting Type: Surface Mount
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 14-SO
  • Base Part Number: LM324
