دیتاشیت SN74LS243N

مشخصات دیتاشیت

دانلود دیتاشیت SN54LS242-43, SN74LS242-43	SN54LS242-43, SN74LS242-43 Datasheet

RoHS: true
Category: Logic ICs/Buffer/Driver/Transceiver
Datasheet: Texas Instruments SN74LS243N
Input type: -
output type: Push Pull
Logic Family: 74LS
Sink Current: 24mA
Source Current: 15mA
Supply Voltage: 4.75V~5.25V
Number of Channels: 4
Operating Temperature: 0°C~+70°C
Package: PDIP-14
Manufacturer: Texas Instruments
Number of Elements: 1
Voltage - Supply: 4.75V ~ 5.25V
Mounting Type: Through Hole
Packaging: Tube
Package / Case: 14-DIP (0.300", 7.62mm)
Number of Bits per Element: 4
Part Status: Active
Current - Output High, Low: 15mA, 24mA
Series: 74LS
Supplier Device Package: 14-PDIP
Logic Type: Transceiver, Non-Inverting
Base Part Number: SN74LS24
detail: Transceiver, Non-Inverting 1 Element 4 Bit per Element Push-Pull Output 14-PDIP
