دیتاشیت ADS5270IPFP

ADS5270

مشخصات دیتاشیت

نام دیتاشیت ADS5270
حجم فایل 1339.05 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت ADS5270

ADS5270 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments ADS5270IPFP
  • Interface: serial
  • resolution: 12Bit
  • Supply Voltage: 3V~3.6V
  • differential input: Yes
  • number of channels: 8
  • sampling frequency: 40MHz
  • Operating Temperature: -40°C~+85°C
  • Package: HTQFP-80(12x12)
  • Manufacturer: Texas Instruments
  • Architecture: Pipelined
  • Input Type: Differential
  • Series: -
  • Ratio - S/H:ADC: 1:1
  • Packaging: Tray
  • Data Interface: LVDS - Serial
  • Reference Type: External, Internal
  • Part Status: Active
  • Supplier Device Package: 80-HTQFP (12x12)
  • Number of A/D Converters: 8
  • Sampling Rate (Per Second): 40M
  • Configuration: S/H-ADC
  • Package / Case: 80-TQFP Exposed Pad
  • Mounting Type: Surface Mount
  • Base Part Number: ADS5270
  • Features: Simultaneous Sampling
  • Number of Bits: 12
  • Number of Inputs: 8
  • Voltage - Supply, Analog: 3V ~ 3.6V
  • Voltage - Supply, Digital: 3V ~ 3.6V
