دیتاشیت STR2550
مشخصات دیتاشیت
| نام دیتاشیت |
STR2550
|
| حجم فایل |
542.555
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
STMicroelectronics STR2550
-
Transistor Type:
PNP
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
500mA
-
Power Dissipation (Pd):
500mW
-
Transition Frequency (fT):
-
-
DC Current Gain (hFE@Ic,Vce):
100@50mA,10V
-
Collector Cut-Off Current (Icbo):
10uA
-
Collector-Emitter Breakdown Voltage (Vceo):
500V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
300mV@50mA,10mA
-
Package:
SOT-23
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
500mA
-
Voltage - Collector Emitter Breakdown (Max):
500V
-
Vce Saturation (Max) @ Ib, Ic:
300mV @ 10mA, 50mA
-
Current - Collector Cutoff (Max):
10µA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
100 @ 50mA, 10V
-
Power - Max:
500mW
-
Frequency - Transition:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23
-
Base Part Number:
STR1550
-
detail:
Bipolar (BJT) Transistor PNP 500V 500mA 500mW Surface Mount SOT-23
