دیتاشیت SN74LVTH244ADWR

مشخصات دیتاشیت

دانلود دیتاشیت SN(54,74)LVTH244A Datasheet	SN(54,74)LVTH244A Datasheet Datasheet

RoHS: true
Category: Logic ICs/Buffer/Driver/Transceiver
Datasheet: Texas Instruments SN74LVTH244ADWR
Input type: -
output type: Tri-State
Sink Current: 64mA
Source Current: 32mA
Supply Voltage: 2.7V~3.6V
Operating Temperature: -40°C~+85°C
Package: SOP-20-300mil
Manufacturer: Texas Instruments
Number of Elements: 2
Supplier Device Package: 20-SOIC
Series: 74LVTH
Mounting Type: Surface Mount
Base Part Number: SN74LVT
Packaging: Cut Tape (CT)
Number of Bits per Element: 4
Current - Output High, Low: 32mA, 64mA
Package / Case: 20-SOIC (0.295", 7.50mm Width)
Part Status: Active
Logic Type: Buffer, Non-Inverting
Voltage - Supply: 2.7V ~ 3.6V
detail: Buffer, Non-Inverting 2 Element 4 Bit per Element 3-State Output 20-SOIC
