دیتاشیت SN74ABT125PWR

مشخصات دیتاشیت

دانلود دیتاشیت SN(54,74)ABT125 Datasheet	SN(54,74)ABT125 Datasheet Datasheet

RoHS: true
Category: Logic ICs/Buffer/Driver/Transceiver
Datasheet: Texas Instruments SN74ABT125PWR
Input type: -
output type: Tri-State
Sink Current: 64mA
Source Current: 32mA
Supply Voltage: 4.5V~5.5V
Operating Temperature: -40°C~+85°C
Package: TSSOP-14
Manufacturer: Texas Instruments
Number of Elements: 4
Supplier Device Package: 14-TSSOP
Series: 74ABT
Mounting Type: Surface Mount
Base Part Number: SN74ABT1
Packaging: Cut Tape (CT)
Number of Bits per Element: 1
Current - Output High, Low: 32mA, 64mA
Package / Case: 14-TSSOP (0.173", 4.40mm Width)
Part Status: Active
Logic Type: Buffer, Non-Inverting
Voltage - Supply: 4.5V ~ 5.5V
detail: Buffer, Non-Inverting 4 Element 1 Bit per Element 3-State Output 14-TSSOP
