SN74LV540APWR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LV540APWR |
|---|---|
| حجم فایل | 69.199 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 34 |
دانلود دیتاشیت SN74LV540APWR |
دانلود دیتاشیت |
|---|
سایر مستندات
SN54LV540A, SN74LV540A 31 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74LV540APWR
- Input type: -
- output type: Tri-State
- Logic Family: 74LV
- Sink Current: 16mA
- Source Current: 16mA
- Supply Voltage: 2V~5.5V
- Number of Elements: 1
- Operating Temperature: -40°C~+125°C
- Number of Bits per Element: 8
- Package: TSSOP-20
- Manufacturer: Texas Instruments
- Supplier Device Package: 20-TSSOP
- Series: 74LV
- Mounting Type: Surface Mount
- Base Part Number: SN74LV54
- Packaging: Cut Tape (CT)
- Current - Output High, Low: 16mA, 16mA
- Package / Case: 20-TSSOP (0.173", 4.40mm Width)
- Part Status: Active
- Logic Type: Buffer, Inverting
- Voltage - Supply: 2V ~ 5.5V
- detail: Buffer, Inverting 1 Element 8 Bit per Element 3-State Output 20-TSSOP
