دیتاشیت TLC3702CDR
مشخصات دیتاشیت
| نام دیتاشیت | TLC3702 Datasheet |
|---|---|
| حجم فایل | 1604.741 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت TLC3702 Datasheet |
TLC3702 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Texas Instruments TLC3702CDR
- Output Type: 开集
- Supply Current: 50uA
- Supply Voltage: 3V~16V
- Number of Elements: 2
- Operating Temperature: 0°C~+70°C
- Propagation Delay Time: 4.5us
- Input Bias Current (Ib): 5pA
- Input Offset Voltage (Vos): 5mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): -
- Package: SOP-8
- Manufacturer: Texas Instruments
- Voltage - Input Offset (Max): 5mV @ 10V
- Type: General Purpose
- Supplier Device Package: 8-SOIC
- Mounting Type: Surface Mount
- Current - Quiescent (Max): 50µA
- Propagation Delay (Max): 4.5µs
- Current - Input Bias (Max): 5pA @ 5V
- Base Part Number: TLC370
- Packaging: Cut Tape (CT)
- Hysteresis: -
- Series: LinCMOS™
- Current - Output (Typ): 20mA
- CMRR, PSRR (Typ): 84dB CMRR
- Part Status: Active
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Voltage - Supply, Single/Dual (±): 3V ~ 16V
- detail: Comparator General Purpose CMOS, Push-Pull, TTL 8-SOIC
