دیتاشیت SN74LVCH16373ADGGR

SN74LVCH16373A

مشخصات دیتاشیت

نام دیتاشیت SN74LVCH16373A
حجم فایل 1016.716 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت SN74LVCH16373A

SN74LVCH16373A Datasheet

مشخصات

  • RoHS: true
  • Series: 74LVCH
  • Category: Logic ICs/Latches
  • Datasheet: Texas Instruments SN74LVCH16373ADGGR
  • Logic Type: D-Typelocking Latch
  • Output Type: Tri-State
  • Sink Current: 24mA
  • Source Current: 24mA
  • Supply Voltage: 1.65V~3.6V
  • Propagation Delay: 2.1ns
  • OperatingTemperature: -40°C~+85°C
  • Package: TSSOP-48-6.1mm
  • Manufacturer: Texas Instruments
  • Delay Time - Propagation: 2.1ns
  • Supplier Device Package: 48-TSSOP
  • Package / Case: 48-TFSOP (0.240", 6.10mm Width)
  • Circuit: 8:8
  • Mounting Type: Surface Mount
  • Base Part Number: SN74LVCH1
  • Packaging: Cut Tape (CT)
  • Voltage - Supply: 1.65V ~ 3.6V
  • Current - Output High, Low: 24mA, 24mA
  • Independent Circuits: 2
  • Operating Temperature: -40°C ~ 85°C
  • Part Status: Active
  • detail: D-Type Transparent Latch 2 Channel 8:8 IC Tri-State 48-TSSOP
