دیتاشیت TPS40193DRCR
مشخصات دیتاشیت
| نام دیتاشیت | TPS40192, TPS40193 |
|---|---|
| حجم فایل | 3533.607 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 37 |
دانلود دیتاشیت TPS40192, TPS40193 |
TPS40192, TPS40193 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS40193DRCR
- Input Voltage: 4.5V~18V
- Number of Outputs: 1
- Switching Frequency: 300kHz
- Output Current (Max): 20A
- Synchronous Rectification: Yes
- Package: DFN-10(3x3)
- Manufacturer: Texas Instruments
- Output Phases: 1
- Series: -
- Output Configuration: Positive
- Output Type: Transistor Driver
- Clock Sync: No
- Packaging: Cut Tape (CT)
- Synchronous Rectifier: Yes
- Voltage - Supply (Vcc/Vdd): 4.5V ~ 18V
- Supplier Device Package: 10-VSON (3x3)
- Duty Cycle (Max): 85%
- Serial Interfaces: -
- Frequency - Switching: 300kHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Base Part Number: TPS401
- Part Status: Active
- Control Features: Enable, Power Good
- Package / Case: 10-VFDFN Exposed Pad
- detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 10-VSON (3x3)
