دیتاشیت ADS1220IPWR
مشخصات دیتاشیت
| نام دیتاشیت | ADS1220 Datasheet |
|---|---|
| حجم فایل | 3049.793 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 74 |
دانلود دیتاشیت ADS1220 Datasheet |
ADS1220 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS1220IPWR
- Interface: SPI
- resolution: 24Bit
- Supply Voltage: 2.3V~5.5V
- differential input: Yes
- number of channels: 2;4
- sampling frequency: 2kHz
- Operating Temperature: -40°C~+125°C
- Package: TSSOP-16
- Manufacturer: Texas Instruments
- Architecture: Sigma-Delta
- Sampling Rate (Per Second): 2k
- Series: -
- Voltage - Supply, Analog: 2.3V ~ 5.5V, ±2.5
- Input Type: Differential, Single Ended
- Number of A/D Converters: 1
- Number of Bits: 24
- Voltage - Supply, Digital: 2.3V ~ 5.5V
- Packaging: Cut Tape (CT)
- Reference Type: External, Internal, Supply
- Ratio - S/H:ADC: -
- Configuration: MUX-PGA-ADC
- Supplier Device Package: 16-TSSOP
- Data Interface: SPI
- Base Part Number: ADS1220
- Features: PGA, Temperature Sensor
- Number of Inputs: 2, 4
- Mounting Type: Surface Mount
- Part Status: Active
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
