دیتاشیت STS4DNFS30L

STS4DNFS30L

مشخصات دیتاشیت

نام دیتاشیت STS4DNFS30L
حجم فایل 305.483 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت STS4DNFS30L

STS4DNFS30L Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: STripFET™
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 30V
  • Current - Continuous Drain (Id) @ 25°C: 4A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 5V, 10V
  • Rds On (Max) @ Id, Vgs: 55mOhm @ 2A, 10V
  • Vgs(th) (Max) @ Id: 1V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 9nC @ 5V
  • Vgs (Max): ±16V
  • Input Capacitance (Ciss) (Max) @ Vds: 330pF @ 25V
  • FET Feature: Schottky Diode (Isolated)
  • Power Dissipation (Max): 2W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-SO
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Base Part Number: STS4D
  • detail: N-Channel 30V 4A (Tc) 2W (Tc) Surface Mount 8-SO
