STTH12R06D دیتاشیت

STTH12R06D

مشخصات دیتاشیت

نام دیتاشیت STTH12R06D
حجم فایل 48.821 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

دانلود دیتاشیت STTH12R06D

دانلود دیتاشیت

سایر مستندات

STTH12R06 11 pages

STTH12R06D 11 pages

مشخصات فنی

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: STMicroelectronics STTH12R06D
  • Diode Configuration: -
  • Reverse Voltage (Vr): 600V
  • Operating Temperature: +175°C@(Tj)
  • Forward Voltage (Vf@If): 2.9V@12A
  • Reverse Leakage Current: 45uA@600V
  • Reverse Recovery Time (trr): 45ns
  • Average Rectified Current (Io): 12A
  • Package: TO-220-2
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 600V
  • Current - Average Rectified (Io): 12A
  • Voltage - Forward (Vf) (Max) @ If: 2.9V @ 12A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 45µA @ 600V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: TO-220-2
  • Supplier Device Package: TO-220AC
  • Operating Temperature - Junction: 175°C (Max)
  • Base Part Number: STTH12R
  • detail: Diode Standard 600V 12A Through Hole TO-220AC
