SN74LS51N دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN74LS51N
|
|
حجم فایل
|
65.325
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
RoHS:
true
-
Series:
74LS
-
Category:
Logic ICs/Gates
-
Datasheet:
Texas Instruments SN74LS51N
-
Sink Current:
8mA
-
Source Current:
400uA
-
Supply Voltage:
4.75V~5.25V
-
Logic Gate Type:
And;ORGate
-
Number of Channels:
2
-
Operating Temperature:
0°C~+70°C
-
Package:
PDIP-14
-
Manufacturer:
Texas Instruments
-
Output Type:
Single-Ended
-
Supplier Device Package:
14-PDIP
-
Schmitt Trigger Input:
No
-
Package / Case:
14-DIP (0.300", 7.62mm)
-
Mounting Type:
Through Hole
-
Base Part Number:
SN74LS51
-
Packaging:
Tube
-
Voltage - Supply:
4.75V ~ 5.25V
-
Number of Circuits:
2
-
Current - Output High, Low:
400µA, 8mA
-
Number of Inputs:
10 Input (3, 3, 2, 2)
-
Part Status:
Active
-
Logic Type:
AND/OR/INVERT Gate
-
detail:
AND/OR/INVERT Gate Configurable 2 Circuit 10 Input (3, 3, 2, 2) Input 14-PDIP
