دیتاشیت UC2843AN

UC2842A(43A), UC3842A(43A)

مشخصات دیتاشیت

نام دیتاشیت UC2842A(43A), UC3842A(43A)
حجم فایل 368.194 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت UC2842A(43A), UC3842A(43A)

UC2842A(43A), UC3842A(43A) Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Output Type: Transistor Driver
  • Function: Step-Up, Step-Up/Step-Down
  • Output Configuration: Positive
  • Topology: Boost, Flyback
  • Number of Outputs: 1
  • Output Phases: 1
  • Voltage - Supply (Vcc/Vdd): 8.4V ~ 30V
  • Frequency - Switching: Up to 500kHz
  • Duty Cycle (Max): 96%
  • Synchronous Rectifier: No
  • Clock Sync: No
  • Serial Interfaces: -
  • Control Features: Frequency Control
  • Operating Temperature: -25°C ~ 85°C (TA)
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: UC284
  • detail: Boost, Flyback Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-PDIP
