دیتاشیت VNW100N04

VNW100N04

مشخصات دیتاشیت

نام دیتاشیت VNW100N04
حجم فایل 293.479 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت VNW100N04

VNW100N04 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: OMNIFET™, VIPower™
  • Packaging: Tube
  • Part Status: Obsolete
  • Switch Type: General Purpose
  • Number of Outputs: 1
  • Ratio - Input:Output: 1:1
  • Output Configuration: Low Side
  • Output Type: N-Channel
  • Interface: On/Off
  • Voltage - Load: 35V (Max)
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 35A
  • Rds On (Typ): 12mOhm (Max)
  • Input Type: Non-Inverting
  • Features: -
  • Fault Protection: Current Limiting (Fixed), Over Temperature, Over Voltage
  • Operating Temperature: -
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247-3
  • Package / Case: TO-247-3
  • Base Part Number: VNW100
  • detail: Power Switch/Driver 1:1 N-Channel 35A TO-247-3
