دیتاشیت BAS70KFILM

BAS70

مشخصات دیتاشیت

نام دیتاشیت BAS70
حجم فایل 182.305 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت BAS70

BAS70 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: STMicroelectronics BAS70KFILM
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 70V
  • Forward Voltage (Vf@If): 1V@15mA
  • Reverse Leakage Current (Ir): 10uA@70V
  • Average Rectified Current (Io): 70mA
  • Package: SOD-523
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 70V
  • Current - Average Rectified (Io): 70mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 1V @ 15mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 10µA @ 70V
  • Capacitance @ Vr, F: 2pF @ 0V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SC-79, SOD-523
  • Supplier Device Package: SOD-523
  • Operating Temperature - Junction: 150°C (Max)
  • Base Part Number: BAS70
