XCR3256XL-12TQG144C Datasheet
Datasheet specifications
| Datasheet's name | XCR3256XL-12TQG144C |
|---|---|
| File size | 121.56 KB |
| File type | |
| Number of pages | 13 |
Download Datasheet XCR3256XL-12TQG144C |
Download Datasheet |
|---|
Other documentations
XCR3256XL 13 pages
CoolRunner XPLA3 CPLD 12 pages
Technical specifications
- RoHS: true
- Category: Single Chip Microcomputer/Microcontroller/Programmable Logic Device (CPLDs/FPGAs)
- Datasheet: XILINX XCR3256XL-12TQG144C
- Package: TQFP-144(20x20)
- Manufacturer: XILINX
- Series: CoolRunner XPLA3
- Packaging: Tray
- Part Status: Active
- Programmable Type: In System Programmable (min 1K program/erase cycles)
- Delay Time tpd(1) Max: 10.8ns
- Voltage Supply - Internal: 3V ~ 3.6V
- Number of Logic Elements/Blocks: 16
- Number of Macrocells: 256
- Number of Gates: 6000
- Number of I/O: 120
- Operating Temperature: 0°C ~ 70°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 144-LQFP
- Supplier Device Package: 144-TQFP (20x20)
- Base Part Number: XCR3256XL
- detail: IC CPLD 256MC 10.8NS 144TQFP
