دیتاشیت SN74ALS1034N
مشخصات دیتاشیت
| نام دیتاشیت | SN54/74ALS1034A |
|---|---|
| حجم فایل | 1163.237 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 19 |
دانلود دیتاشیت SN54/74ALS1034A |
SN54/74ALS1034A Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74ALS1034N
- Input type: -
- output type: Tri-State
- Logic Family: 74ALS
- Sink Current: 24mA
- Source Current: 15mA
- Supply Voltage: 4.5V~5.5V
- Number of Elements: 6
- Operating Temperature: 0°C~+70°C
- Number of Bits per Element: 1
- Package: PDIP-14
- Manufacturer: Texas Instruments
- Voltage - Supply: 4.5V ~ 5.5V
- Package / Case: 14-DIP (0.300", 7.62mm)
- Series: 74ALS
- Base Part Number: SN74ALS1
- Supplier Device Package: 14-PDIP
- Mounting Type: Through Hole
- Logic Type: Buffer, Non-Inverting
- Packaging: Tube
- Current - Output High, Low: 15mA, 24mA
- Part Status: Active
