دیتاشیت SN74S260N
مشخصات دیتاشیت
| نام دیتاشیت | SN54S260, SN74S260 |
|---|---|
| حجم فایل | 1005.209 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت SN54S260, SN74S260 |
SN54S260, SN74S260 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Logic ICs/Gates
- Datasheet: Texas Instruments SN74S260N
- Package: PDIP-14
- Manufacturer: Texas Instruments
- Voltage - Supply: 4.75V ~ 5.25V
- Logic Level - Low: 0.8V
- Number of Circuits: 2
- Package / Case: 14-DIP (0.300", 7.62mm)
- Series: 74S
- Max Propagation Delay @ V, Max CL: 6ns @ 5V, 15pF
- Number of Inputs: 5
- Base Part Number: SN74S2
- Mounting Type: Through Hole
- Features: -
- Supplier Device Package: 14-PDIP
- Logic Type: NOR Gate
- Packaging: Tube
- Operating Temperature: 0°C ~ 70°C
- Current - Output High, Low: 1mA, 20mA
- Part Status: Active
- Logic Level - High: 2V
- detail: NOR Gate IC 2 Channel 14-PDIP
