SN54,74(LS,S)51 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN54,74(LS,S)51
|
|
حجم فایل
|
1114.101
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
Voltage - Supply:
4.75V ~ 5.25V
-
Base Part Number:
SN74S5
-
Number of Circuits:
2
-
Package / Case:
14-DIP (0.300", 7.62mm)
-
Series:
74S
-
Number of Inputs:
8 Input (2, 2, 2, 2)
-
Supplier Device Package:
14-PDIP
-
Mounting Type:
Through Hole
-
Output Type:
Single-Ended
-
Logic Type:
AND/OR/INVERT Gate
-
Packaging:
Tube
-
Manufacturer:
Texas Instruments
-
Operating Temperature:
0°C ~ 70°C
-
Current - Output High, Low:
1mA, 20mA
-
Part Status:
Active
-
Schmitt Trigger Input:
No
-
detail:
AND/OR/INVERT Gate Configurable 2 Circuit 8 Input (2, 2, 2, 2) Input 14-PDIP
